Cable-hung linear pendant from the Vario series with a flush opal snap-in lens, 350-1,000 lm/ft direct output plus optional uplight, 2700-4000K or tunable white, in 4/6/8 ft and custom lengths.
| Wattage | 4.28–12.63 W/ft |
|---|---|
| Luminous flux | 350–1000 lm/ft |
| Efficacy | 79 lm/W |
| Color temperature (CCT) | 2700K / 3000K / 3500K / 4000K |
| CRI | ≥80 |
| Mounting | Pendant (aircraft cable, 48" standard), Surface, Recessed |
| Dimensions | 4-1/4" W x 4-3/4" H profile (4-1/4" x 5-1/2" with uplight); 4/6/8 ft nominal lengths + custom lengths in 1" increments |
| Distribution | Direct, Direct/Indirect |
| Finishes | White, Black, Silver, Custom (RAL/Pantone powder coat, wood, anodized aluminum, chrome/gold plating) |
| Dimming | 0-10V 1% dimming standard; non-dim, Lutron EcoSystem 1%, Lutron Athena wireless node, 2-circuit direct/indirect wiring, custom controls; DALI/DMX/PoE on request; universal 110-277 VAC |
| Rated environments | Dry, Damp location |
| Rated lifetime | 50,000 h |
| Warranty | 5 years |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Vario Flush Lens is the linear-only pendant in Picasso Lighting's Vario series, designed mainly for retail, office, and library settings. The extruded-aluminum housing measures 4-1/4" wide by 4-3/4" high (4-1/4" by 5-1/2" when indirect uplight is added, with the uplight housing 1 inch larger) and comes in nominal 4, 6, and 8 ft lengths, custom lengths in 1-inch increments, and continuous rows. Its flush opal-white snap-in lens is designed for high LED output while hiding the LED image, with delivered output of 350, 500, 750, or 1,000 lm/ft direct (4.28-12.63 W/ft, with published indirect values of 4-11.4 W/ft for uplight sections). Standard CCTs run 2700K to 4000K with 80+ or 90+ CRI, plus tunable white 2700-5000K on linear sections; drivers are high-power-factor universal 110-277 VAC with 0-10V 1% dimming standard and non-dim, Lutron EcoSystem, Lutron Athena wireless, two-circuit direct/indirect wiring, emergency-battery, and PoE/DALI/DMX options. The series is also available in Surface and Recessed versions and in custom shapes such as triangles, squares, and rectangles. Fixtures are IBEW-manufactured and assembled in the USA, UL listed for dry and damp locations, rated for 50,000-hour LED life, and covered by a limited five-year warranty.
Pick from Vario Flush Lens's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
Submittal summary
