Quick-ship round linear LED pendant kit delivering 500 lm/ft direct at 3500K/90+ CRI, in 4 and 8 ft sections joinable into runs up to 48 ft on one power supply.
| Wattage | 5.5 W/ft |
|---|---|
| Luminous flux | 500 lm/ft |
| Efficacy | 91 lm/W |
| Color temperature (CCT) | 3500K |
| CRI | ≥90 |
| Mounting | Pendant (aircraft cable) |
| Dimensions | 4 ft and 8 ft nominal lengths; continuous rows up to 48 ft with one power supply |
| Distribution | Direct |
| Finishes | White |
| Dimming | 0-10V 1% dimming, 120V/277V; universal 110-277 VAC |
| Rated environments | Dry, Damp location |
| Rated lifetime | 50,000 h |
| Warranty | 5 years |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Nicole EZ-P is the quick-ship, no-submittal version of Picasso Lighting's round Nicole pendant, built for individual fixtures or continuous rows up to 48 ft fed from a single power supply: order one power/end-cap kit per run plus as many joiner kits as needed, with no waiting for submittals, drawings, bills of materials, or approvals. The extruded-aluminum housing comes in nominal 4 and 8 ft lengths with a tool-less snap-on gear tray, snap-on frosted acrylic round lens, and milled end caps and joiners that eliminate light leaks. Direct-only output is fixed at 500 lm/ft, 5.5 W/ft (90 lm/W) at 3500K and 90+ CRI, in standard white with white 5" canopies and power cord. The driver is universal 120/277 VAC with 0-10V 1% dimming, and an emergency battery-backup driver is optional. Cable mounting uses gripper-style locking on 48" support cables to a standard J-box canopy. Fixtures are IBEW manufactured and assembled in the USA, UL listed for dry and damp locations, with 50,000-hour rated LED life and a five-year limited warranty.
Pick from Nicole EZ-P Individual and Continuous's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
