Square-lens linear LED pendant delivering 350 to 1000 lm/ft direct at up to 122 lm/W, 2700-4000K, in 3/4/6/8 ft lengths with cable or stem mounting and Surface and Wall variants.
| Wattage | 2.88–8.48 W/ft |
|---|---|
| Luminous flux | 350–1000 lm/ft |
| Efficacy | 118 lm/W |
| Color temperature (CCT) | 2700K / 3000K / 3500K / 4000K |
| CRI | ≥80 |
| Mounting | Pendant (aircraft cable / stem), Surface, Wall |
| Dimensions | 1-13/16" W x 3-1/16" H profile; 3/4/6/8 ft nominal lengths + custom (1 in. increments), continuous rows available |
| Distribution | Direct |
| Finishes | White, Black, Silver, Custom (RAL/Pantone powder coat, wood, anodized, chrome/gold plating) |
| Dimming | 0-10V 1% dimming standard (120V or 277V); non-dim, Lutron EcoSystem 1%; DALI/DMX/PoE on request; universal 110-277 VAC |
| Rated environments | Dry, Damp location |
| Rated lifetime | 50,000 h |
| Warranty | 5 years |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Emily Dropped Lens is the square-lens counterpart to Picasso Lighting's Nicole, a direct-only linear pendant sized for general lighting at 500 lm/ft with 8-10 ft spacing. The extruded-aluminum housing shares the 3-1/16" H x 1-13/16" W profile and comes in nominal 3, 4, 6, and 8 ft lengths plus custom sizes in 1-inch increments, continuously rowable, with milled-aluminum end caps (magnetic screwless end caps optional); the extruded square snap-in frosted acrylic lens runs up to a nominal 4 ft maximum section length. Four output packages span 350 to 1000 lm/ft at 2.88 to 8.48 W/ft (118-122 lm/W at 3000K), in 2700/3000/3500/4000K at 80+ or 90+ CRI, with tunable white (2700-5000K) and custom lumen tuning available. Drivers are universal 110-277 VAC with 0-10V 1% dimming standard; non-dim, Lutron EcoSystem 1%, and DALI/DMX/PoE controls are available, plus an optional emergency battery-backup driver. Cable mounting uses gripper-style locking on 48" standard cables to a J-box canopy (stem mounting available), and the series is also offered in Surface and Wall versions. Fixtures are IBEW manufactured and assembled in the USA, UL listed for dry and damp locations, with 50,000-hour rated LED life and a five-year limited warranty.
Pick from Emily Dropped Lens's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
