Suspended indirect/direct architectural linear on Finelite's Elements platform, with a 1-1/8-inch-wide profile and published output from 378 to 923 delivered lm/ft.
| Luminous flux | 378–923 lm/ft |
|---|---|
| Color temperature (CCT) | 3000K / 3500K / 4000K |
| CRI | ≥80 |
| Mounting | Pendant / suspended (off-grid, adjustable power cable) |
| Dimensions | 2-1/4 in H × 1-1/8 in W profile; runs from 2 ft minimum in 1/16 in increments (8 ft maximum section length) |
| Distribution | Indirect/Direct |
| Finishes | Signal White, Finelite Black, Satin Aluminum, Custom RAL |
| Dimming | 0–10V, 10%–100% standard; 1% option, DALI 1%, and Lutron EcoSystem 1%; Dim-to-Off (DTO) option; separate uplight/downlight dimming on runs 3 ft and greater |
| Rated environments | Damp location, Chicago Plenum option |
| Rated lifetime | 60,000 h |
| Warranty | 10 years |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Finelite's E2 Indirect/Direct (E2-ID) is a suspended architectural linear luminaire built on the Elements platform, pairing a Top Glow uplight diffuser with a flush downlight diffuser for independent up/down control. The precision-cut 6063-T6 extruded aluminum body measures 2-1/4 in tall by 1-1/8 in wide and is assembled from 2 ft minimum sections in 1/16-inch increments up to an 8 ft maximum section length. Four lumen packages — Standard, Boosted, High, and Very High — publish 378 to 923 delivered lm/ft at 3500K, 80 CRI (uplight 230–563 lm/ft, downlight 147–360 lm/ft), with a tailored option between Standard and Very High. Static-white 3000K, 3500K, and 4000K are offered in 80 or 90 CRI. The luminaire suspends off-grid on adjustable power cables fed from in-ceiling power supply boxes (low profile, large capacity, retrofit, and remote), with 15/16 in and 9/16 in T-bar, screw-slot, hard-ceiling, and open-to-structure hardware. Dimming is 0–10V from 10% standard with 1%, DALI, and Lutron EcoSystem options. E2 is rated for damp locations, has L90 lumen maintenance at 60,000+ hours, and carries a 10-year warranty.
Pick from E2 Indirect/Direct's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
Submittal summary
