High-output integral-driver cove profile (1-9/16" x 2-1/8") publishing up to 2200 lm/ft at 15.9 W/ft, in 2-8 ft lengths with 2700-4000K CCTs and white, black, or RAL finishes.
| Wattage | 15.9 W/ft |
|---|---|
| Luminous flux | 1500–2200 lm/ft |
| Efficacy | 138 lm/W |
| Color temperature (CCT) | 2700K / 3000K / 3500K / 4000K |
| CRI | ≥80 |
| Mounting | Surface (cove) |
| Dimensions | 1-9/16" W x 2-1/8" H profile; 2/3/4/6/8 ft nominal lengths + custom |
| Distribution | Indirect |
| Finishes | White, Black, RAL colors |
| Dimming | 0-10V dimming 1% (120/277V) or non-dim standard; Lutron EcoSystem 1% optional; PoE/DALI/DMX and custom controls on request; universal 110-277 VAC |
| Rated environments | Dry, Damp location |
| Rated lifetime | 50,000 h |
| Warranty | 5 years |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Cove-200 is the high-output profile in Picasso Lighting's integral-driver Cove Series, a 1-9/16" wide by 2-1/8" tall extruded-aluminum channel for ambient, wall-wash, and accent lighting in coves facing up or down. The LED performance table publishes a Super High package at 15.9 W/ft delivering 2200 lm/ft (110 lm/W at 3000K), with 1500 and 2000 lm/ft indirect packages offered on the spec sheet and custom lumen outputs available. No low-voltage wiring is required — 120 or 277 V feeds the side or back through a 1/2" knockout with quick connects supplied, and the integral powder-coated LED housing carries a clear dust lens. Standard CCTs run 2700K to 4000K in 80+ or 90+ CRI (3 SDCM), with tunable white and warm dim available. Lengths are 2, 3, 4, 6, and 8 ft nominal plus custom; drivers are 0-10V dimming (1%) or non-dim at 120/277 V, with Lutron EcoSystem 1% and custom controls optional. Finishes are standard white, standard black, or specified RAL colors. IBEW manufactured and assembled in the USA, UL listed for dry and damp locations, rated 50,000-hour LED life, and covered by a limited five-year warranty.
Pick from Cove-200's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
Submittal summary
