Slimmest of Picasso's three integral-driver Cove Series profiles (1-13/16" x 2-1/8") delivering 350-1000 lm/ft at 2700-4000K in 2-8 ft lengths for surface-mounted cove installation.
| Wattage | 2.98–8.8 W/ft |
|---|---|
| Luminous flux | 350–1000 lm/ft |
| Efficacy | 114 lm/W |
| Color temperature (CCT) | 2700K / 3000K / 3500K / 4000K |
| CRI | ≥80 |
| Mounting | Surface (cove) |
| Dimensions | 1-13/16" W x 2-1/8" H profile; 2/3/4/6/8 ft nominal lengths + custom |
| Distribution | Direct, Indirect |
| Finishes | White, Custom (consult factory) |
| Dimming | 0-10V dimming 1% (120/277V) or non-dim standard; Lutron EcoSystem 1% optional; PoE/DALI/DMX and custom controls on request; universal 110-277 VAC |
| Rated environments | Dry, Damp location |
| Rated lifetime | 50,000 h |
| Warranty | 5 years |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Cove-100 is the tool-less member of Picasso Lighting's integral-driver Cove Series, a 1-13/16" wide by 2-1/8" tall extruded-aluminum channel for ambient, wall-wash, and accent lighting recessed in a cove facing up or down. The board-and-driver assembly services without tools, and the fixture needs no low-voltage wiring — 120 or 277 V feeds the side or back through a 1/2" knockout, with quick connects supplied for installation. The LED performance table publishes 350, 500, 750, and 1000 lm/ft indirect packages at 2.98-8.8 W/ft (114-119 lm/W at 3000K), with a 2200 lm/ft package and custom lumen outputs also orderable; photometry is published for both direct and indirect orientations behind a clear dust lens. Standard CCTs run 2700K to 4000K in 80+ or 90+ CRI (3 SDCM), with tunable white and warm dim available. Lengths are 2, 3, 4, 6, and 8 ft nominal plus custom; drivers are 0-10V dimming (1%) or non-dim at 120/277 V, with Lutron EcoSystem 1% and custom controls optional. IBEW manufactured and assembled in the USA, UL listed for dry and damp locations, rated 50,000-hour LED life, and covered by a limited five-year warranty.
Pick from Cove-100's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
